Air Conditioning
Fan Coil Units
ECOAIR Fan coil Units are a complete line of fan coil units to meet most air
conditioning requirements. Fan coil units manufactured by ECOIR have been designed with the requirements of the Middle East market foremost in consideration. Fan coil units are ideally suited for installation in chilled water or to meet the air conditioning requirements of individual rooms throughout the year. Increasingly, architects require a hidden indoor unit with a custom enclosure to match the aesthetic requirements of the space.
Models
- EALS Series
- EAHS Series
Fan Coil Units
Specifications
High efficiency coil with high-efficiency wavy corrugated fins.
Hi-efficiency, low power consumption PSC electric motor / EC motor Optional.
Hi-efficiency forward curved fan for quiet operation.
Manual air vent.
Heavy gauge galvanised casing & fan housing. Hot dip is standard.
Insulated heavy gauge drain pan.
Quick electrical connections
Casing: 0.9 mm thick Galvanized Steel.
Insulation: 10 mm thick irradiated PE/NBR foam on coil section
Drain Pan: 0.9 mm thick Galvanized powder coated with 5mm PE/NBR insulation
Coil: 9.52 mm OD, 0.32 mm thick Copper tube & 0.105 mm mild rippled and die formed slit
Aluminum blue fins with hydrophilic coating
Fan: High Efficiency GI rolled direct driven Centrifugal forward curved Fan with Steel Wheels.
Minimize Noise and Vibration.
Motor: Open shielded foot mounted IP 20 protected motor with class B insulation.
Filter: 7mm thick aluminum washable type MERV-3
Ecoair Fan coil units are certified in accordance with AHRI-440 standard
